APC Easy UPS BVX 700VA, 230V, AVR, IEC Sockets BVX700LI
December 31 - 01
Battery type : Lead-acid battery
Typical recharge time : 8hour(s)
Nominal Battery Voltage : 12 V
Replacement Battery : APCRBC110
Expected Battery Life (years) : 3 - 5
Details
APC Easy UPS BVX 700VA, 230V, AVR, IEC Sockets BVX700LI
Output
Max Configurable Power (Watts) : 360 Watts / 700VA
Output Frequency (sync to mains) : 50/60 Hz +/- 1 Hz Sync to mains
Topology : Line interactive
Waveform type : Stepped approximation to a sinewave
Transfer Time : 6 ms typical : 10 ms maximum
Input
Input frequency : 50/60 Hz +/- 5 Hz Auto sensing
Input voltage range for main operations : 140 - 300 (230 V) ACV
Number of Power Cords : 1
Input Power Factor at Full Load : 0.51
Communications & Management
Control panel : LED Status display with on line : on battery
Audible Alarm : Alarm when on battery : distinctive low battery alarm
Surge Protection and Filtering
Surge energy rating : 273Joules
Physical
Maximum Height : 138MM, 13.8CM
Maximum Width : 98MM, 9.8CM
Maximum Depth : 310MM, 31.0CM
Net Weight : 4.2KG
Color : Black
SCC Codes : 10731304404481
Environmental
Operating Temperature : 0 - 40 °C
Operating Relative Humidity : 0 - 95 (Non-condensing) %
Operating Elevation : 0 - 3000meters
Storage Temperature : -15 - 40 °C
Storage Relative Humidity : 0 - 95 (Non-condensing) %
Storage Elevation : 0 - 3000meters
Audible noise at 1 meter from surface of unit : 40.0dBA
Protection Class : IP20
More Information
Part No | BVX700LI |
---|---|
Dimensions Length (inch) | 12.20 |
Dimensions Width (inch) | 3.85 |
Dimensions Height (inch) | 5.43 |
Country of Manufacture | China |
Brand | APC by Schneider Electric |
Battery Type | Lead-acid |
Battery Life | 3 - 5 |
