Aruba 2930F 48G PoE+ 4SFP+ 740W Switch

Be the first to review this product

Expected dispatch on : 0December 23 - 24

Part No JL558A

Differentiator Next-generation family of stackable access switches ideal for enterprise branch offices, campuses and SMB networks. 24x 10/100/1000BASE-T and 4x 1/10G SFP ports 370W of available Class 4 PoE power.

Power consumption65W at 230 VAC

Input voltage100V-120V/200V-240V

Ports24x 10/100/1000BASE-T Class 4 PoE ports 4x 1/10G SFP ports Supports PoE Standards IEEE 802.3af, 802.3at 1x USB-C Console Port 1x OOBM 1x USB Type-A Host port 1x Bluetooth Adapter to be used with Aruba CX Mobile App

Latency1 Gbps: 2.28 μSec 10 Gbps: 1.46 μSec

Routing/switching capacity128 Gbps

Stacking capabilities8 members

ThroughputUp to 95.2 Mpps

Memory and processorQuad Core ARM Cortex™ A72 @ 1.8 GHz

Power supply nameFixed power supply (500W) Up to 370W of Class 4 PoE Power

PoE capability370W

AED 16,305.54
Inclusive of 5% VAT

Details

Aruba 2930F 48G PoE+ 4SFP+ 740W Switch

Enterprise-class connectivity with support for ACLs, robust QoS, and common protocols such as static and Access OSPF routing.
Scalability with 8 member VSF stacking. 24 and 48-port fixed and modular switch models can stack together for up to 384 ports.
Models include modular switches with 1/10GbE uplinks, LRM, and MACSec 256, fixed switches with either 1/10GbE SFP+ or 1GbE SFP uplinks, and options that support 30W to 60W of PoE per port.
Intelligent monitoring and visibility via Aruba Network Analytics Engine. Aruba NetEdit support for automation, configuration and verification. One touch deployment using the Aruba CX Mobile App.
Aruba Dynamic Segmentation enables enhanced security and simple access for users and IoT.
Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency.

Detailed product descriptionAruba 6200F 24G Class4 PoE 4SFP+ 370W Switch. Includes Non-Pluggable, Internal PSU behind sheetmetal Chassis. Frame Includes Non-Pluggable, Internal Fans behind sheetmetal Chassis Frame
Min=0 \ Max = 4 SFP/SFP+ 1/10G Transceiver
1U - Height
Weight4.90 kg (10.80 lbs)
Dimensions4.39 x 44.2 cm x 32.7 cm (1.73 x 17.4 x 12.9 in)

More Information

More Information
Part No	JL558A
GTIN-/EAN-Code	0190017219660
UPC	190017219660
ASIN	B0791H463T
Dimensions Length (inch)	1.73
Dimensions Width (inch)	17.42
Dimensions Height (inch)	12.77
Brand	Aruba Networks
Switches	PoE
PoE Capability	740 W PoE+
Memory and Processor	Dual Core ARM Cortex A9 @ 1016 MHz 1 GB DDR3 SDRAM Packet buffer size: 12.38 MB 4.5MB Ingress/7.875MB Egress 4 GB eMMC
Throughput	up to 112 Mpps
Switching Capacity	176 Gbps
Voltage	100-127 / 200-240 VAC, rated
