D-Link DWC-2000 Wireless Controller

DWC-2000 Wireless Controller

The D-Link DWC-2000 Wireless Controller is a centralized wireless LAN manager designed specifically for campus, hospitality, and medium-to-large enterprise environments. With the ability to manage up to 64  (upgradable to 2561) wireless access points, and up to a maximum of 1,024 wireless access points in a controller cluster, the DWC-2000 is a cost-effective mobility solution suitable for medium-to-large scale deployments. Its auto-managed AP discovery and single point management allow customers to acquire an enterprise-class system without the burden of maintaining massive and complex configurations.

Simplified Deployment and Management

Using the intuitive setup wizard, the DWC-2000 can be easily configured for any network. Centralized management of remote access points via a simple interface provides administrators with the convenience of automatically discovering compatible D-Link wireless access points, adding them to the managed access point list, and performing one-time configurations. The network administrator can use the controller clustering feature to easily log into one wireless controller and apply configuration changes to other access points in the group.

The web interface dashboard displays real-time status information of all access points and associated client stations, allowing for efficient network resource management. Furthermore, the graphical widgets on the dashboard can be customized to provide various client and network statistics at a glance. Combined with system alarms and statistical reports on managed access points, the DWC-2000 provides a central platform that allows administrators to effectively optimize and manage their wireless network environment.

Guest Control and Management

The DWC-2000 integrates guest management features that deliver a secure and easy solution for managing guest access to a private or public network. Each issued temporary account (ticket) is accompanied by time or bandwidth-limited Internet access privileges. The guest management feature allows administrators to generate a batch of temporary accounts and provide account details to guests via printout. Administrators can monitor and manually adjust the bandwidth and time limit for each new issued account ticket. The DWC-2000 furthermore allows administrators to set up payment gateways, allowing users to purchase network access online using electronic payments.

Robust and Optimized Network

The DWC-2000 features self-organizing, self-optimizing, and self-healing network capabilities to increase the stability of the entire wireless network. A maximum of 4+4 wireless controller redundancy and AP provisioning automatically transfers AP management from a failed controller to the a backup controller in emergency scenarios, providing optimal reliability. Through regular radio scanning and performance analysis, the DWC-2000 automatically adjusts radio channels and transmitting power periodically to avoid interference and keep the wireless network optimized. In the event of a sudden loss of wireless signal caused by a “dead” access point, the DWC-2000 will increase the transmission output power of neighboring access points to expand RF coverage to maintain a reliable, high performance network.

Comprehensive Security

The DWC-2000 provides a comprehensive wireless security solution for easy integration with any network. The Wireless Intrusion Detection System (WIDS) feature detects rogue access points, rogue clients, and can detect wireless threats, preventing potential breaches and illegal access before any damage is done to the network. In addition to fundamental wireless security, the captive portal feature allows administrators to block clients from accessing the network until their identities are verified. The captive portal authentication servers cover local, RADIUS, LDAP, POP3, and Microsoft Active Directory. These client authentication and authorization layers also create a robust security barrier to avoid attacks from within the network.

High Scalability, Availability, and Flexibility

To address the constantly growing scale and needs of business networks, the DWC-2000 offers several optional features to increase the capacity and flexibility of your wireless network. Administrators can purchase D-Link’s Business Wireless Plus license packs to upgrade the DWC-2000 and increase the supported number of manageable access points, depending on the needs of the network. By default, the DWC-2000 can manage up to 64 access points, which can be expanded to 256 access points per controller. With the DWC-2000, administrators can scale their wireless network to meet higher demands as business grows.
