NETGEAR GS724TP 24-Port Gigabit Ethernet Smart Managed Pro Switch with 24 x PoE 190W, 2 x 1G SFP Dubai, UAE

NETGEAR GS724TPv2 ProSAFE 24-Port Smart Rackmount Gigabit PoE+ Switch w/ 2 x SFP Ports (190W)

ETHERNET PORT CONFIGURATION: 24 Gigabit ports. POWER-OVER-ETHERNET: 24 PoE+ ports with 190W total power budget. FLEXIBILITY FROM UPLINK PORTS: 2 x 1G SFP ports

ADVANCED CONFIGURATION & CONTROL: Management software with an easy-to-use GUI interface offers refined control for secure setup, access, and SNMP (NMS 300) management. VERSATILE MOUNTING OPTIONS

WHISPER-QUIET DESIGN: Reduces fan noise to protect your home office or business environment.

ENERGY EFFICIENT: Designed to optimize power usage lowering its cost to operate. Most models are compliant with IEEE802.3az Energy Efficient Ethernet mode.

BUILT TO LAST: Every NETGEAR Network switch is rigorously tested for reliability, quality, and performance.

Technical specifications

Packet buffer memory (Dynamically shared across only used ports) : 0.5 MB

Forwarding modes : Store-and-forward

Bandwidth: 52 Gbps

Priority queues: 8

Priority queuing: Weighted Round Robin (WRR) and Strict Priority

MAC Address database size (48-bit MAC addresses): 8K

Multicast groups: 128

Number of VLANs: 64

Number of DHCP snooping bindings: 256

Access Control Lists (ACLs): 100 shared for MAC, IP and UDP/TCP ACLs (ingress)

Packet forwarding rate (64 byte packet size) (Mpps) : 38.68

Jumbo frame support: Up to 9K packet size

Acoustic noise level @ 25°C (dBA) (ANSI-S10.12)

• 32.4 dBA

Mean Time Between Failures (MTBF) @ 25°C: 1,051,375 hours

100M Copper Latency(64-byte; 1518-byte; 9216-byte frames): 6.38µs ; 6.267µs ; 6.059µs

1G Copper Latency(64-byte; 1518-byte; 9216-byte frames): 3.749µs ; 4.675µs ; 3.762µs

1G Fiber Latency (64-byte; 1518-byte; 9216-byte frames): 3.129µs ; 4.213µs ; 4.197µs

L2 Services – VLANs

IEEE 802.1Q VLAN tagging: Yes

Auto-VoIP VLAN / Auto-Voice VLAN

• Yes, manuel or automatic assigment of VoIP phone traffic based on OUI bytes (default database and user-based OUIs) in the phone source MAC address to Voice VLAN associated with high priority QoS parameters

L2 Services - Availability

Broadcast, multicast, unknown unicast storm control: Yes

IEEE 802.3ad - LAGs (LACP): Yes

IEEE 802.3x (full duplex and flow control): Yes

IEEE 802.1D Spanning Tree Protocol: Yes

IEEE 802.1w Rapid Spanning Tree Protocol: Yes

IEEE 802.1s Multiple Spanning Tree Protocol: Yes

L2 Services - Multicast Filtering

IGMP snooping (v1, v2 and v3): Yes

IGMP snooping querier: Yes

DHCP Services

DHCP client: Yes

DHCP snooping: Yes

Link Aggregation

IEEE 802.3ad - LAGs (LACP): Yes

Manual Static LAG: Yes

# of Static or LACP LAGs/ # of Members in each LAG: 8 LAGs with max 8 members in each LAG

Network Monitoring and Discovery Services

802.1ab LLDP: Yes

SNMP: v1, v2c, v3

RMON group 1,2,3,9: Yes

Network security

IEEE 802.1x: Yes (EAP)

Guest VLAN: Yes

RADIUS-based VLAN assignment via .1x: Yes

RADIUS accounting: Yes

Access Control Lists (ACLs): L2 / L3 / L4 ingress

IP-based ACLs (IPv4): Yes

MAC-based ACLs: Yes

TCP/UDP-based ACLs: Yes

MAC lockdown: Yes

MAC lockdown by the number of MACs: Yes

Control MAC # Dynamic learned entries: 600

Control MAC # Static entries: 20

IEEE 802.1x RADIUS port access authentication: Yes

Port-based security by locked MAC addresses: Yes

Broadcast, multicast, unknown unicast storm control: Yes

DoS attacks prevention: Yes

Quality of Service (QoS)

Port-based rate limiting: Yes egress

Port-based QoS: Yes

DiffServ QoS: Yes ingress

IEEE 802.1p COS: Yes

Destination MAC and IP: Yes

IPv4 DSCP: Yes

IPv4 ToS: Yes

TCP/UDP-based: Yes

Weighted Round Robin (WRR): Yes

Strict priority queue technology: Yes

Auto-VoIP VLAN / Auto-Voice VLAN

• Yes, manuel or automatic assigment of VoIP phone traffic based on OUI bytes (default database and user-based OUIs) in the phone source MAC address to Voice VLAN associated with high priority QoS parameters

IEEE Network Protocols

• IEEE 802.3 Ethernet
• IEEE 802.3u 100BASE-T
• IEEE 802.1Q VLAN Tagging
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3af PoE
• IEEE 802.3at PoE+
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• IEEE 802.3ad Trunking (LACP)
• IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
• IEEE 802.3x Full-Duplex Flow Control
• IEEE 802.1AB LLDP with ANSI/TIA-1057 (LLDP-MED)
• IEEE 802.1p Class of Service
• IEEE 802.1D Spanning Tree (STP)
• IEEE 802.1s Multiple Spanning Tree (MSTP)
• IEEE 802.1w Rapid Spanning Tree (RSTP)
• IEEE 802.1x RADIUS Network Access Control

Management

Password management: Yes

Configurable management VLAN: Yes

Admin access control via RADIUS and TACACS+: Yes

SNTP client over UDP port 123: Yes

SNMP v1/v2c: Yes

SNMP v3 with multiple IP addresses: Yes

RMON group 1,2,3,9: Yes

Port mirroring: Yes

Many-to-one port mirroring: 25

Web browser-based graphical user interface (GUI): Yes

Smart Control Center (SCC) for multi-switch management: Yes

Dual software (firmware) image: Yes

Cable test utility: Yes

HTTPS/TLS Web-based access (version): Yes (v1.0)

File transfers (uploads, downloads) TFTP / HTTP

HTTP upload/download (firmware): Yes

Syslog (RFC 3164): Yes

LEDs

Per port: Speed, Link, Activity

Per device: Power and Fan

Physical specifications

Dimensions (W x D x H)

• 440 x 204 x 43 mm
• (17.3 x 8 x 1.7 in)

Weight

• 3.15 kg
• (6.96 lb)

Power consumption

Max power (worst case, all ports used, full PoE, line-rate traffic) (Watts): 228.53 W

Max power without PoE (worst case, all ports used, line-rate traffic) (Watts): 21.62 W

Heat Dissipation (worst case, all ports used, full PoE, line-rate traffic) (BTU/hr): 780.20 BTU/hr

Heat Dissipation without PoE (worst case, all ports used, line-rate traffic) (BTU/hr): 73.8 BTU/hr

Energy Efficient Ethernet (EEE) IEEE 802.3az: Yes (deactivated by default)

Short Cable Power Reduction: Yes (deactivated by default)

Auto Power Down: Yes (deactivated by default)

Fan: 2

Environmental specifications

Operating

Power Internal: 100-240VAC 50-60Hz

Operating temperature: 0 to 50C (32 to 122F)

Humidity (relative): 90% maximum relative humidity (RH), non-condensing

Altitude: 10,000ft (3,000m) maximum

Storage

Storage temperature: –20 to 70C (– 4 to 158F)

Humidity (relative): 95% maximum relative humidity, non-condensing

Altitude: 10,000ft (3,000m) maximum

Electromagnetic Emissions and Immunity

Certifications

• CE: EN 55032:2012+AC:2013/CISPR 32:2012, EN 61000-
• 3-2:2014, Class A, EN 61000-3-3:2013, EN 55024:2010
• VCCI : VCCI-CISPR 32:2016, Class A
• RCM: AS/NZS CISPR 32:2013 Class A
• CCC: GB4943.1-2011; YD/T993-1998; GB/T9254-2008 (Class A)
• FCC: 47 CFR FCC Part 15, Class A, ANSI C63.4:2014
• ISED: ICES-003:2016 Issue 6, Class A, ANSI C63.4:2014
• BSMI: CNS 13438 Class A

Safety

Certifications

• CB report / certificate IEC 60950-1:2005
• (ed.2)+A1:2009+A2:2013
• UL listed (UL 1950)/cUL IEC 950/EN 60950
• CE LVD: EN 60950-1: 2006 + A11:2009 + A1:2010 +
• A12:2011 + A2:2013
• RCM (AS/NZS) 60950.1:2015
• CCC (China Compulsory Certificate): GB4943.1-2011; YD/
• T993-1998; GB/T9254-2008 (Class A)
• BSMI: CNS 14336-1

Warranty and Support

• ProSAFE Lifetime Warranty
• Included, Lifetime* (excluding mounting hardware, belts or straps)
• Lifetime 24x7 Online Technical Support*
• Included, Lifetime*
• Lifetime Next-Business-Day (NBD) Replacement
• Included, Lifetime*
• ProSUPPORT OnCall 24x7, Service Packs**
• Category 1: PMB0311 (1 yr.), PMB0331 (3 yrs.), PMB0351 (5 yrs.)

Package content

• 24-Port Gigabit Ethernet PoE+ Smart Managed Pro Switch
• Power cord (localized to country of sale)
• Rack-mounting kit
• Rubber footpads for tabletop installation
• Quick install guide
• Resource CD with installation guides, Smart Control Center utility software, MIB files, and links to additional online documentation including the Web browser-based management
• GUI User Manual and datasheet.
