Ubiquiti PowerBeam PBE M5 400 High Performance airMAX Bridge

Ubiquiti
Expected dispatch on : February 24 - 25
Part No PBE-M5-400

Gain : 25 dBi
Networking Interface : (1) 10/100/1000 Ethernet Port
Enclosure : Outdoor UV Stabilized Plastic
Max. Power Consumption : 8W
Max. TX Power : 26 dBm
Power Supply : 24V, 0.5A Gigabit PoE Adapter
Power Method : Passive PoE
Wind Survivability : 200 km/h
Wind Loading : 342.5 N @ 200 km/h
Mounting : Pole Mounting Kit Included
Salt Fog Test : IEC 68-2-11
Equivalent: MIL-STD-810 G Method 509.5
Vibration Test : IEC 68-2-6
Temperature Shock Test : IEC 68-2-14
UV Test : IEC 68-2-5 at 40° C
Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test : ETS 300 019-1-4
Equivalent: MIL-STD-810 G Method 506.5
Operating Temperature : -40 to 70° C
Operating Humidity : 5 to 95% Noncondensing

Quote

Details


Ubiquiti PowerBeam PBE M5 400 High Performance airMAX Bridge

Integrated Radio Design
Ubiquiti’s InnerFeed® technology integrates the radio into the feedhorn of an antenna, so there is no need for cables to connect the radio to the antenna. This improves performance because it eliminates cable losses.

Plug and Play Installation
The PowerBeam™ requires no tools for assembly; only a single wrench is required for pole-mounting.

Incredible Antenna “Beam” Performance
The form factor of the PowerBeam™ features the highest gain for its size. The PowerBeam’s excellent beam directivity provides the best performance in high-noise environments.

Advanced Software Technology
Ubiquiti’s airMAX® technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.


More Information


More Information
Part No PBE-M5-400
GTIN-/EAN-Code 0688474343535
UPC 688474343535
Dimensions Length (inch) 19
Dimensions Width (inch) 9
Dimensions Height (inch) 19
Country of Manufacture China
Brand Ubiquiti
