Switch Pro Aggregation

Expected dispatch on : February 15 - 16

Part No USW-Pro-Aggregation-EU

Layer 3 switch with (28) 10G SFP+ ports and (4) 25G SFP28 ports.

The Switch Pro Aggregation is a fully managed, Layer 3 switch with (28) 10G SFP+ ports and (4) 25G SFP28 ports designed to enhance your network's switching capacity and performance by creating high-bandwidth aggregation links. This rack-mountable switch also offers 760 Gbps switching capacity and features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.

Quote

Details

Switch Pro Aggregation

Mechanical

Dimensions: 442 x 325 x 44 mm (17.4 x 12.8 x 1.7")
Weight Without Mount: 4.6 kg (10.14 lb)
With Mount: 4.7 kg (10.36 lb)
Enclosure Material: GCC Steel

Hardware

Total Non-Blocking Throughput: 380 Gbps
Switching Capacity: 760 Gbps
Forwarding Rate: 565.44 Mpps
Max. Power Consumption: 100W
Power Method: (1) Universal AC input, 100-240VAC, 2A Max, 50/60 Hz
(1) USP-RPS DC input, 11.5VDC, 8.7A
Power Supply: AC/DC, Internal, 100W
Network Interface: (28) 1/10 Gbps SFP+ Ethernet
(4) 1/10/25 Gbps SFP28 Ethernet*
LCM Display:(1) 1.3" Touchscreen
Bootup Animation: Bootup in Progress
Firmware Upgrade Icon:Firmware Upgrading
Steady White:Factory Defaults, Awaiting Adoption
Steady Blue: Device is Adopted
LEDs SFP28/SFP+: White, Link and Activity
Management Interface: Ethernet In-Band
Modes: SMB Layer 3 10/25 G Fiber Switch
ESD/EMP Protection:Air: ± 16kV, Contact: ± 12kV
Operating Temperature: -5 to 40° C (23 to 104° F)
Operating Humidity: 10 - 90% Noncondensing
Certifications: CE, FCC, IC
